FTTH Figure 8 Drop Cable Steel Messenger
Waveoptics® FTTH Figure 8 Drop Cable is an economical, small factor, self-supporting cable, optimal for indoor/outdoor applications and is ideal for longer distance external use, compared to FTTH Drop Cable. The flat design offers easy stripping with no tools, simplifying the installation process.
APPLICATIONS
Not Applicable for G652.D fiber type
- Description
- Additional information
- Properties
- Data Sheets
Description
FTTH Figure 8 Drop Cable Steel Messenger
Waveoptics® FTTH Figure 8 Drop Cable is an economical, small factor, self-supporting cable, optimal for indoor/outdoor applications and is ideal for longer distance external use, compared to FTTH Drop Cable. The flat design offers easy stripping with no tools, simplifying the installation process.
For self-supporting applications, a galvanized steel messenger consisting of 7 steel wires with a total diameter of 1.2 mm is incorporated.
The optical fiber is positioned in the center of the cable, parallel KFRP´s (Kevlar Fiber Reinforced Plastic) rods located on both sides as reinforcement against crushing and traction forces, protecting the fibers.
Additional information
| Fiber Count | 1 Fiber, 2 Fibers, 4 Fibers |
|---|---|
| Fiber Type | Waveoptics G652.D, Waveoptics G657.A1, Waveoptics G657.A2, Waveoptics G657.B3 |
| Cable Length | 1,000 m (3,281 ft), 2,000 m (6,562 ft) |
Design Properties
| Fiber Count | 1-4 |
| Nominal Outer Dimensions | 5 mm x 2 mm (0.2 in x 0.08) (±5%) |
| Dielectric Strength Member | KFRP |
| Messenger Diameter | Steel: 0.047in FRP: 0.60in |
| Outer Jacket Material / Color | LSZH / Black |
| Reel Length | 3,281 ft & 6,562 ft (±5%) |
Temperature Range
| Operation | -20°C to 70°C (-4°F to 158°F) |
| Installation | -40°C to 70°C (-40°F to 128°F) |
| Storage / Transport | -40°C to 70°C (-40°F to 128°F) |
Mechanical Properties
| Tensile Strength (Long-Term / Short-Term) | Steel (300 N / 600 N) & KFRP (230 N / 460 N) |
| Crush Resistance (Long-Term / Short-Term) | 1,000 N/100mm / 2,200 N/100mm |
| Maximum Bend Radius (Operation / Installation) | 10 x OD / 20 x OD |
