Node Fiber Optic Service Cable Assemblies
MEXFOSERV® Node Fiber Optic Service Cable Assemblies, also known as node tails, drop node assemblies or amplifier drop cable assemblies, make splicing from an optical node to a closure fast, easy and reliable in a CATV network.
- Description
- Additional information
- General Characteristics
- Standards
- Data Sheet
Description
Node Fiber Optic Service Cable Assemblies
MEXFOSERV® is a complete product line of connectivity related products to support high speed telecommunications. Our designs offer the best quality and engineering solutions for every necessity and an excellent integration for network management.
MEXFOSERV® Node Fiber Optic Service Cable Assemblies, also known as node tails, drop node assemblies or amplifier drop cable assemblies, make splicing from an optical node to a closure fast, easy and reliable in a CATV network. This cable assembly features a rugged design that provides the end-user with factory pre-terminated and tested cables eliminating labor and time at the node location.
These cables offer an environmental seal between the cable and the node housing and come with a node fitting pre-installed on the cable, the mounting thread is an industry standard that
helps prevent fiber breaks, leaks, kinks and avoid problems in the field for CATV networks.
Application
• CATV
Additional information
| Fiber Number | 8 Fibers, 12 Fibers |
|---|---|
| Connector Type | SC/UPC, SC/APC, LC/UPC, LC/APC |
| Cable Type | Dielectric, 2mm Breakout, Armored, 2mm Breakout |
| Packaging Type | Individual Coil, Plastic Reel Packaging |
| Length | 20 ft, 60 ft, 100 ft, 200 ft, 250 ft, 500 ft |
General Characteristics
| • Available with SC, FC & LC connectors |
| • Tight Sealing |
| • Easy Installation |
| • Available with 2.0mm fan out |
| • Fiber counts available 8 & 12 fibers |
| • Standard 5/8″ – 24 thread |
| • Fiber color coded to TIA 598-C |
Standards
| • GR-326-CORE |
| • IEC 61300-3-35 |
| • TIA/EIA -598-C.3 |
