Loose Tube Double-Armored Double Jacket Cable

Waveoptics® Loose Tube Double-Armored Double Jacket Cable is designed for direct-buried installation, as well as for duct and aerial (lashed) installation.
PE double jacket with additives makes a resistant, durable and easy to strip cable, providing superior protection against  UV radiation, fungus, abrasion and other environmental factors.

APPLICATIONS
PROTECTIONS

Clear

Description

Loose Tube Double-Armored Double Jacket Cable
Waveoptics® Loose Tube Double-Armored Double Jacket Cable is designed for direct-buried installation, as well as for duct and aerial (lashed) installation.
PE double jacket with additives makes a resistant, durable and easy to strip cable, providing superior protection against  UV radiation, fungus, abrasion and other environmental factors.
The SZ-stranded method for loose tubes and four ripcords ensure a quick and easy mid-span access.
Dielectric central strength member requires no bonding or grounding.
Corrugated steel armor makes a rugged cable and offers exceptional performance against compression. Double-armored design offers superior protection against rodents.

Additional information

Fiber Count

2 Fibers, 4 Fibers, 6 Fibers, 8 Fibers, 12 Fibers, 24 Fibers, 36 Fibers, 48 Fibers, 60 Fibers, 72 Fibers, 96 Fibers, 144 Fibers, 192 Fibers, 216 Fibers

Fiber Type

Waveoptics G652.D, Waveoptics G657.A1, Waveoptics G657.A2, OFS G652.D, OFS AllWave® FLEX

Cable Length

10,000 ft, 15,000 ft, 20,000 ft

LT Water Protection

Dry, Gel-Filled

Loose Tube Material

PBT, PP

Design Properties

Fiber per Tube 2-12
Dielectric Strength Member FRP
Outer Jacket Material / Thickness Polyethylene / 1.6 mm (0.06 in)
Inner Jacket Material / Thickness Polyethylene / 0.8 mm (0.03 in)
Loose Tube Diameter 2.5 mm (0.1 in)
Drum Length 10,000 ft, 15,000 ft & 20,000 ft (±5%)

Temperature Range

Operation -40°C to 70°C (-40°F to 158°F)
Installation -30°C to 70°C (-22°F to 158°F)
Storage / Transport -40°C to 70°C (-40°F to 158°F)

Mechanical Properties

Crush Resistance (Short-Term / Long-Term) 4,400 N/100mm / 2,200 N/100mm
Minimum Bend Radius (Operation / Installation) 10 x OD / 20 x OD
